Product Description
Technical Specifications
The Through Conduit Slab Gate Valve is designed and manufactured following stringent industry standards to ensure performance and reliability:
- Design & Manufacturing Standard: API 6D
- Face-to-Face Standard: ASME B16.10 / API 6D
- Flanged Ends Standard: ASME B16.5 / MSS-SP-44
- Testing & Inspection Standard: API 598 / API 6D
Product Range
The Through Conduit Slab Gate Valve is available in a variety of materials, sizes, and pressure ratings to meet different operational needs:
- Body Material: Carbon Steel, Stainless Steel, Alloy Steel, Monel, Duplex, Inconel
- Size Range: 2” – 72”
- Pressure Rating: Class 150 – Class 2500
- End Connection: RF, RTJ, BW
- Working Temperature: -46℃ to +200℃
- Mode of Operation: Handwheel, Gearbox, Electric, Pneumatic, etc.
